SIMPLEX 4090 9116 Addressable IDNET ISOLATOR Module 0617994

SIMPLEX 4090 9116 Addressable IDNET ISOLATOR Module 0617994

Dual port, bi-directional communications short circuit isolator:



  • Compatible with Simplex® 4007ES, 4008, 4010ES, 4100ES, or 4100U Series fire alarm control panel IDNet Signaling Line Circuits (SLCs) providing: IDNet, IDNet+, IDNet 1+, IDNet 2, or IDNet 2+2 output loops (see additional information on pages 2 and 3)
  • Either port can serve as an input or output, ports are automatically separated when a communications short circuit occurs
  • Isolation can also be activated from the control panel for system diagnostics
  • Mounts in standard 4” (102 mm) square electrical box, optional adapter plate is available to mount in a 4 11⁄16” (119 mm) square electrical box
  • LED flashes to indicate communications; optional covers are available to view LED after installation
  • TrueAlarm sensor base IDNet Isolators are also available, refer to data sheet S4098-0025 for details
  • UL listed to Standard 864

PRODUCT SELECTION

4090-9116 Addressable IDNet Communications Isolator
4090-9813 Adapter plate to fit 4 11⁄16” (119 mm) square electrical box
4090-9801 For semi-flush mounted box Optional trim plate with LED viewing window, includes mounting screws; galvanized steel
4090-9802 For surface mounted box
Category:

Description

4090-9116 In order to enhance system integrity and facilitate installation, addressable IDNet communications isolaters offer IDNet communications isolation. When an output short circuit is detected, isolation is automatically triggered. To help troubleshoot wiring issues, isolation can also be manually selected from the control panel.

Operation: The control panel instructs the isolators to connect after they are powered up in isolation mode. The isolator will connect to the remainder of the circuit if the output wiring is acceptable. The isolator stays isolated even if the output wiring is shorted.
